Big Blue Water Filter Housing Kit with 10" Cartridges

Product detailed description

The complete Big Blue 10" filtration kit is designed for efficient water filtration in households. The kit removes mechanical impurities and sediments and helps improve water quality for further use.

Package includes:

• filter head with pressure relief (vent) button
• robust Big Blue filter housing
• filter wrench for easy opening and cartridge replacement
• mounting bracket including screws
• 2× polypropylene sediment filter cartridges, 5 micron
• 2× DMfit push-fit connectors M3/4" × 9.5 mm for 9.5 mm tubing

Main features:

• suitable for a wide range of applications (residential, commercial and industrial)
• effective filtration of mechanical impurities and sediments
• easy installation thanks to the complete accessory set
• simple maintenance with a pressure relief valve
• durable construction for long service life

Technical specifications:

• Flow rate: up to 10.6 GPM (approx. 40 l/min)
• Housing colour: blue
• Inlet: 3/4" female thread (FPT)
• Outlet: 3/4" female thread (FPT)
• Filter length: 10"
• Compatible cartridges: 4.5" × 10"
• Temperature range: 4–38 °C
• Maximum operating pressure: 90 PSI
• Pressure drop: approx. 1 PSI at 15 GPM

This kit is an ideal solution if you are looking for a reliable and easy-to-install water filter with the option of direct connection to 9.5 mm tubing using DMfit push-fit connectors.

Applications in Brewing

• This wound polypropylene cartridge is also well suited for preparing brewing water. By removing fine sediments, rust and suspended particles, it improves mash consistency, lautering efficiency and overall wort clarity. Cleaner water supports stable enzyme activity and reduces the risk of haze-forming compounds entering the wort.
• The cartridge is also a valuable pre-filter for pumps, heat exchangers and reverse osmosis systems used in breweries. By reducing particulate load, it helps prevent clogging, protects seals and extends equipment lifetime. Suitable for water used in mashing, sparging, sanitation and cooling processes.
• Ideal as a pre-filter for brewing water — improves mash and wort quality, protects pumps and chillers, and reduces sediment load before RO or heating/cooling systems.
